TISMO
Extra super fine fibers for the future
TISMO was born in 1979, and it has been used for many years. We have been constantly expanding its range of applications in several industrial fields, such as automobiles, office automation equipments, and electronic equipments.
“TISMO” is potassium titanate fiber shown with K2Ti8O17 or K2Ti6O13, and has the very thin form of a fiber length 10-20µm, a fiber diameter 0.3-0.6µm.
“TISMO” has high strength, high rigidness, many advantages from the high-aspect-ratio, and it is used in wide application fields such as reinforcement of plastics, friction material for the automobile, and precise filter.
Advantages
- It is a fine and crystalline fiber. It has the size of about one thousandth of the general glass fiber.
- It is high strength, and high-rigid material. It has the strength and rigidity equivalent to the carbon fiber.
- It is optimum for the friction material. It has a Mohs hardness equivalent to cast iron, and it has the excellent friction and wear property.
Applications
Friction materials（Automotive brake pad, brake lining, clutch, motorcycle brake pad etc.）
Plastics additives（Precision parts, anti-wear parts, heat-resistance parts）
Heat resistant paints
Ion exchange uses
Filters（Diesel engine filter）
General Properties
| TISMO D | TISMO N | ||
|---|---|---|---|
| Chemical composition | – | K2O・8TiO2 | K2O・6TiO2 |
| Appearance | – | White powder | White powder |
| Average fiber diameter | μm | 0.3～0.6 | 0.3～0.6 |
| Average fiber length | μm | 10～20 | 10～20 |
| True density | g/cm3 | 3.3～3.5 | 3.4～3.6 |
| Water content | mass% | <0.7 | <0.7 |
| pH (dispersed in water) | – | 9～10 | 7～8 |
| Melting point | ℃ | 1,300～1,350 | 1,300～1,350 |
| *Mohs hardness | – | 4 | 4 |
| *Tensile strength | GPa | 7 | 7 |
| *Tensile modulus | GPa | 280 | 280 |
| *Electric resistance | Ω・m | 3.3×1015 | 3.3×1015 |
*Literature data
